Configuration Guide RSPAN Configuration
Ruijie(config-if)# { switchport access vlan vid
| switchport trunk native vlan vid }
Vid: VID for remote-span vlan.
If the destination port is acess port, join the
destination port to remote-span vlan;
If the destination port is trunk port, join the
destination port to remote-span vlan and set
the remote-span vlan as the native vlan for
the destination port.
Configuring Flow-based RSPAN
As the expansion of local SPAN, RSPAN supports flow-based mirroring as well. For
details, refer to Mirroring Configuration Guide.
Flow-based RSPAN brings no influence on communications.
Users can set ACL at the inbounding direction of the source port
of the source RSPAN switch. Standard ACL, extended ACL, MAC
ACL and user-defined ACL are supported.
Users can set port ACL at the inbounding direction of the source
port of the source RSPAN switch, and set port ACL at the
outbounding direction of the destination port of the destination
RSPAN switch.
Users can apply ACL at the outbounding direction of Remote
VLAN on the soruce RSPAN switch, and apply ACL at the
inboudning direction of Remote VLAN on the destination RSPAN
switch.
Show the mirroring configuation.
For example:
Ruijie# show monitor
sess-num: 1
src-intf:
GigabitEthernet 0/4 frame-type Both
dest-intf:
GigabitEthernet 0/6
remote vlan 3
