Sakura Tissue-Tek Prisma Plus User Manual

Troubleshooting
4-2
Error
number
Name
Cause
Action
21
Door Open
The operator opened a door while the arm was removing
a basket from a station in the frontmost row during the
staining process.
Close the door and resume the
process.
The operator opened a door while the arm was storing a
basket into a station in the frontmost row during the
staining process.
Close the door and resume the
process.
An incompletely latched door suddenly opened during
the staining process.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The instrument malfunctioned during the staining process
due to a door open/close sensor error.
The instrument malfunctioned during the staining process
due to a controller board input error.
The control panel connection harness connecting the
CPU board of the control panel and the controller board
shorted during the staining process.
The instrument malfunctioned during the staining process
due to an input error of the CPU board of the control
panel.
The instrument malfunctioned during the staining process
due to a CPU error of the CPU board of the control
panel.
45
Bar Code
Reader Circuit
Overcurrent
The bar code reader or connection cable is faulty.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The external I/F board is faulty.
The controller board is faulty.
The external I/F connection harness is faulty.
50
Exhaust Fan
Stop
The exhaust fan stopped due to an error of the fan.
Contact the Sakura Finetek
Technical Support representative
or local representative.
Due to an error of the exhaust fan, the fan stop detection
signal was output even when the fan was turning.
Due to a sensor input error of the controller board, the
fan stop detection signal was not transmitted.
The wiring exhaust fan relay harness experienced a
contact failure/disconnection.
70
Battery Voltage
Low
The battery unit reached its life.
Contact the Sakura Finetek
Technical Support representative
or local representative.
80
Motor Unit
Communication
Error
The control panel connection harness was disconnected.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The CPU board of the control panel is faulty.
The controller board is faulty.
81
I/O Unit
Communication
Error
The control panel connection harness was disconnected.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The CPU board of the control panel is faulty.
The controller board is faulty.
90
Vacuum
Breaker Error
Water leaked and caused the float switch to operate.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The float switch malfunctioned.
The switch malfunctioned due to a sensor input error of
the controller board.
100
Robotic Arm
Error
Deviation of each axis
Contact the Sakura Finetek
Technical Support representative
or local representative.
Program error
111
Home Position
Sensor Error
(X axis)
The X-axis slow-down sensor is faulty.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The X-axis home sensor is faulty.
The controller board is faulty.
112
Wire Slack
(X axis)
The X-axis wire assembly is loose.
Contact the Sakura Finetek
Technical Support representative
or local representative.
114
Deviation Error
(X axis)
Movement of the X-axis is inhibited by an obstacle or
faulty wire drive.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The X-axis home sensor is faulty.
The X-axis encoder is faulty.
The X-axis motor is faulty.
The controller board is faulty.
115
Wire Cut Off
(X axis)
The X-axis wire broke or came off from the pulley, etc.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The X-axis wire breakage sensor is faulty.
The controller board is faulty.
211
Home Position
Sensor Error
(Y axis)
The Y-axis slow-down sensor is faulty.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The Y-axis home sensor is faulty.
The controller board is faulty.
212
Wire Slack
(Y axis)
The Y-axis wire assembly is loose.
Contact the Sakura Finetek
Technical Support representative
or local representative.
