Sakura Tissue-Tek Prisma Plus User Manual

Troubleshooting
4-3
Error
number
Name
Cause
Action
214
Deviation Error
(Y axis)
Movement of the Y-axis is inhibited by an obstacle or faulty
wire drive.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The Y-axis home sensor is faulty.
The Y-axis encoder is faulty.
The Y-axis motor is faulty.
The controller board is faulty.
215
Wire Cut Off (Y axis)
The Y-axis wire broke or came off from the pulley, etc.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The Y-axis wire breakage sensor is faulty.
The controller board is faulty.
311
Home Position Sensor
Error
(Z axis)
The Z-axis home sensor is faulty.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The controller board is faulty.
312
Wire slack (Z axis)
The Z-axis wire assembly is loose.
Contact the Sakura Finetek
Technical Support representative
or local representative.
314
Deviation Error
(Z axis)
Movement of the Z-axis is inhibited by an obstacle or
faulty wire drive.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The Z-axis home sensor is faulty.
The Z-axis encoder is faulty.
The Z-axis motor is faulty.
The controller board is faulty.
315
Wire Cut Off
(Z axis)
The Z-axis wire broke or came off from the pulley, etc.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The Z-axis wire breakage sensor is faulty.
The controller board is faulty.
430
Sensor Opened
(Drying Station 1)
An abnormal value was input to the signal amplification
part of the controller board due to a disconnected
temperature sensor.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The drying station connection harness connecting the
temperature controller board and the controller board was
disconnected.
A disconnected harness was recognized by CPU1 due to
a signal amplification error of the controller board.
Normal judgment was disabled due to a CPU1 error of the
controller board.
431
Sensor Shorted
(Drying Station 1)
An abnormal value was input to the signal amplification
part of the controller board due to a shorted temperature
sensor.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The drying station connection harness connecting the
temperature controller board and the controller board
shorted.
A shorted harness was recognized by CPU1 due to a
signal amplification error of the controller board.
Normal judgment was disabled due to a CPU1 error of the
controller board.
432
Temperature Low
(Drying Station 1)
Power could not be supplied to the heater due to a
disconnection or connection failure of the heater.
Contact the Sakura Finetek
Technical Support representative
or local representative.
Power could not be supplied to the heater due to a SSR
error of the temperature controller board.
Power could not be supplied to the drying heater due to a
disconnection of the drying station connection harness
connecting the temperature controller board and the
controller board.
Power could not be supplied to the heater due to a CPU1
error of the controller board.
The heater voltage selector switch is set incorrectly.
The power-supply voltage selector switch is set incorrectly.
433
Thermal Fuse (Drying
Station 1)
The SSR3 on the temperature controller board
experienced a short-circuit failure.
Contact the Sakura Finetek
Technical Support representative
or local representative.
The heater remained on due to a driver error of the
controller board.
A false detection occurred due to an error of the SSR1 for
power-supply voltage detection.
The drying station connection harness connecting the
temperature controller board and the controller board was
disconnected.
The instrument malfunctioned due to an over-temperature
protection input error of the controller board.
The heater voltage selector switch is set incorrectly.
The power-supply voltage selector switch is set incorrectly.
