Installation Method
1-11
● Installing the water supply strainer (Prisma-P-ED, ES Only)
Depending on the condition of the maintenance space available on the right side of the instrument,
install the attached water supply strainer on the water supply port, and then connect the water supply
hose.
1. Enough maintenance space of 200 mm or more is available on the right side face of the instrument.
(1) Screw the connection nipple and bushing into the attached strainer.
(2) Screw the attached nipple, and the strainer set assembled in (1), into the water supply port on the
right side face of the instrument.
(3) Screw in the water supply hose, and connect the water supply hose to the tap water supply
according to P. 1-9.
To Next Page
