satmap active 20 - Basic Layout

Software v3.0.11065
© Satmap Systems Ltd 2017
4
ii. BasicLayout
InsertSDCard
LanyardPoint
uBloxMaxGPS
GPSLockIcon
TrailTaken
LocationIcon
microUSB
9Function
Rockerpad
LargeSide/Front
MultifunctionKeys
Side/front press keys
enable one-handed
operation. Buttons are
variable (depending
on the screen shown)
and can be set to
activate with 1-click or
2-click operation .
BacklightBoostButton
ToggleMapIcon
BatteryIndicator
On/Off
3.5in/8.7cm
Bright,Hi-Res
HVGA(320x480)
Screen
Weatherproof,
Toughened
ImpactCasing
Screen : 8.7cm
Width : 7.1cm
Height : 14.7cm
Depth : 3.5cm
Weight : 310g
StatsRecording
BluetoothIcon
PlanningIcon
BacklightLevelIcon
