6. MAINMENU:SettingsMenu(...cont)
29.GoToTime How long to reach GoTo point.
30.GoToVMG (VelocityMadeGood) is the actual
speed you are making toward your chosen location
(POI, Next WP or GoTo point (AOI, LOI, POI, WP or
any unidentified point on the map), rather than your
simple forward speed.
31.NearestPOI* Name of nearest POI/LOI/AOI.
32. Bearing to POI* Bearing to nearest POI/LOI/
AOI.
33. Nearest POI* Distance Distance to nearest
POI/LOI/AOI.
34.POI*ETATime of arrival at nearest POI/LOI/AOI.
35.POI*TimeTime until nearest POI/LOI/AOI.
36.POI*VMGVelocity Made Good to nearest POI/
LOI/AOI. See GoTo VMG summary.
37.RouteNameName of route.
38. Route Distance  Total distance of the active
route.
39.RouteCrossTrackErrorThis is the distance
between the planned blue/yellow route and the snail
trail. It is most relevant for aircraft (cross wind effects)
and nautical applications (effects of currents).
40.RouteDone Percentage of route travelled so
far.
41.WPName Name of next waypoint.
42.BearingNextWP Bearing to the next waypoint.
43.DistanceNextWP Distance to the next waypoint.
44. ETA to Next Estimated Time of Arrival at next
waypoint.
45.TimeNext How long to reach next waypoint.
46.VMGNext Velocity Made Good to next waypoint.
See GoTo VMG summary above.
47.BearingtoEndBearing to the route end.
48.DistancetoEndDistance to route end (along the
route).
49.ETAtoEndEstimated Time of Arrival at route
end.
50.TimetoEndHow long to get to route end.
51.VMGEnd Velocity Made Good to route end. See
GoToVMG
summary.
52.Date.Today's date.
53.PosnasDDMM.MM.Position given as Degrees,
Minutes Decimal
54.PosnasDD.DDDDD. Position given as degrees
decimal, to 5dp.
55.PosnasOSGB.GPS position given as r OSGB
(Ordnance Survey GB); UTM; Degrees
decimal; Degrees, minutes decimal; Degrees,
minutes, seconds decimal; British Grid.
See GPSSettings for other formats.
56.Sunrise Time of sunrise.
57.SunsetTime of sunset.
58.MoonPhaseAn icon is displayed along with the
percentage of a full moon.
59.GPSAccuracy.Given in metres or feet, this is a
measure of the GPS positional accuracy. GPS devices
typically aim for sub-2m for 50% of the time. Clear skies
will give the best reading, whilst very heavy overhead
cover, tall buildings, etc. will see this value deteriorate
(get larger). Typically expect values of 2m-5m.
60.BatteryVoltage.Typically this runs from approx
4.1V to a cut-off level of 3.2V
61.PDOP.Positional Dilution of Precision - this is a ratio
to indicate how accurately the GPS module is recording
the overall positional signal from the Satellites.
62. HDOP. Horizontal Dilution of Precision - this is
a ratio to indicate how accurately the GPS module
is recording the horizontal location signal from the
Satellites.
63.VDOP.Vertical Dilution of Precision - this is a ratio
to indicate how accurately the GPS module is recording
the vertical / elevtaion signal from the Satellites.
64.TDOP.Time Dilution of Precision - this is a ratio to
indicate how accurately the GPS module is recording
the time signal from the Satellites.
65.BatteryLevel.Given as a Percentage
* In the data boxes, data options mentioning
POIs also refer to any reference point of an
LOI and AOI (usually the point at the start of
the name).
*
