Name Description Remark Ref.
PURGE TIME Sets a purge execution time.
Initial value: 3
Set value: 1 to 20 minutes
P.35
PURGE FLOW Sets a purge flow rate.
Initial value: 4.0
Set value:
0.1 to 10.0 mL/min
P.35
PURGE P.MAX
Sets maximum pressure limit at
purging.
Initial value: 10.0
Set value: 1.0 to 10.0 MPa
P.36
RINSING
OPERATE
Sets the delivery amount of the
optional rinsing pump when the
pump is used.
Initial value: 0 (OFF)
Set value: 0 to 4
P.36
FLOW SLOPE
Sets the time to reach the set
flow rate during delivery.
Initial value: 0
Set value:
0 to 30.00 minutes
P.37
* Do not change the factory default value.
n [CONTROL] settings group
Name Description Remark Ref.
PLUNGER SET
Moves the plunger position.
Replace the plunger or the
plunger seal.
Initial value: 0
Set value:
0: Stop 1: L 2: R 3: M
P.37
ZERO ADJUST
Performs zero adjustment of
pressure screen.
- P.37
MODE
CHANGE
(Only for LC-40D XR CL)
Switches between the constant
flow delivery mode and the
constant pressure delivery mode.
Initial value: 0
Set value:
0: Constant flow
1: Constant pressure
P.38
n [SYSTEM] setting group
Name
Description Remark Ref.
LOCAL MODE
Selects independent operation or
control via system controller.
Initial value: 0
Set value:
0: Remote 1: Local
P.38
LINK ADDRESS
Sets address of the instrument for
control via system controller.
Initial value: 4
Set value: 1 to 12
P.38
CONTROLLER
LINK
Selects the type of the connected
system controller.
Initial value: 1
Set value: 0: Int 1: Ext
P.39
SELECT EVENT1 Not used in CL model.* Initial value: 0 -
SELECT EVENT2 Not used in CL model.* Initial value: 0 -
PUMP CONFIG
(SYS)
Input values according to the
system used.
Initial value: 1
Set value:
1: Standard
4: Low-pressure gradient
mode
P.40
SYSTEM
PROTECT
Reduces the flow rate without
stopping the pumping when the
pressure exceeds the P.MAX
value.
Initial value: 0
Set value: 0: Clear 1: Set
P.40
LC-40D X3 CL LC-40D XR CL
29
3.5 Auxiliary Functions Screen (FUNCTION)
3
