Caution
Instructions
Use a correctly connected cable.
The connection method and special accessory RS-232C cable described below do not guarantee
normal operation with all types of PC.
When using the WindowsDirect communication function, see "WindowsDirect Communication
Function" (^ page 111).
Cable Connection Method
For IBM PC/AT, DOS/V, and AX PC (D-sub 9-pin) (Straight connection)
PC Side Balance Side
RXD 2 2 TXD
TXD 3 3 RXD
DTR 4 4 DSR
SG 5 5 SG
DSR 6 6 DTR
RTS 7 7 CTS
CTS 8 8 RTS
NC 9 9


Connecting to a PC
(RS-232C)
