Removing the Glass Door
With small pan models of the TW/TX series of balances, the glass door can be removed to clean
the door rails.
Caution
Instructions
Handle the glass door with due care.
Take care when handling the glass door so as not to crack it.
Take care not to injure your hands on the door rail.
Exercise due care when handling broken glass.
•
•
•
1
Remove the pan and pan supporter.
2
Turn the knob on the inner side of
the handle to remove the handle.
Caution
Prohibitions
Do not touch the pan support
shaft.
This could damage the balance.
3
Pull the glass door out from the
rear.
Caution
Instructions
When tting the glass door,
be sure to t the knob.
If you forget to t the knob the
glass door could fall off.

PanPan supporter
Pan support
shaft
PanPan supporter
Pan support
shaft
HandleHandle
