Shimadzu TXB2201L - Specifications; TW;TX Series

BEFORE
WEIGHING
USING THE
BALANCE
USING MORE CONVENIENTLY MAINTENANCE
TROUBLESHOOTING
FOR YOUR
INFORMATION
145
Continued on next page

TW/TX Series
Model Name
TWC323L
TXC323L
TWC623L
TXC623L
TW223L
TX223L
TW323L
TX323L
TW423L
TX423L
TX2202L TX3202L TX4202L
Weighing capacity
320 ct
(64 g)
620 ct
(124 g)
220 g 320 g 420 g 2200 g 3200 g 4200 g
Minimum
indication
0.001 ct
(0.0002 g)
0.001 ct
(0.0002 g)
0.001 g 0.001 g 0.001 g 0.01 g 0.01 g 0.01 g
Range of external
weights for
calibration
10 - 64 g 10 - 124 g 100 - 220 g 100 - 320 g 100 - 420 g 1000 - 2200 g 1000 - 3200 g 1000 - 4200 g
Repeatability
(standard deviation)
≤ 0.0002 g ≤ 0.001 g ≤ 0.01 g
Linearity
± 0.0004 g ± 0.002 g ± 0.02 g
Response time
*1
3.0 seconds 2.5 seconds
Ambient
temperature
5 - 40 °C
Temperature
coefcient for
sensitivity
(10 - 30 °C)
± 3 ppm/°C
Pan size (mm) Approx. f80
Approx. f110
Approx. 167 (W) × 181 (D)
*2
Main body
dimensions (mm)
Approx. 206 (W) × 291 (D) × 241 (H)
Approx.
200 (W) × 291 (D) × 80 (H)
Main body weight
TWC: approx. 4.1 kg
TXC: approx. 3.8 kg
TW: approx. 4.2 kg
TX: approx. 3.8 kg
TW: approx. 3.2 kg
TX: approx. 2.8 kg
Display LCD with backlight
Power
requirements
AC adaptor (Output 12 V, 1 A)
I/O terminal RS-232C, DATA I/O
*1
The response time is a representative value.
*2
The size of the pan is the dimension of the face on which the sample (thing being weighed) is placed.
The dimension expresses the at face size of the pan. Since the pan has a tapered shape, its outer dimension
is a little larger.

Specications
