137
Message Display Probable Cause(s) Countermeasure See:
ERR H
(Hardware error)
There is a fault in the hardware,
such as the temperature sensor
or internal weight mechanism
(TW series only).
There is an error in the internal
system data.


Disconnect the AC adaptor or
remove the batteries and turn
the power back ON. If the same
message is still displayed,
contact your Shimadzu
representative.

Page 31
ERR C
(Span calibration error)
The balance has a large drift of
the zero point or sensitivity.
A container is placed on the
pan.
The pan is displaced.
The wrong weight has been
placed on the pan.




Press ( with the TXB
series) to return to the weighing
mode. Place the correct weight
in the center of the pan.
After checking that the pan
is correctly installed and that
nothing is placed on it, turn the
power back ON and execute
span calibration again.


Page 56
Page 60
ERR N
(Numerical value entry
error)
Either a mistake has been made
when entering the value or the
value is not appropriate.

After the error is displayed, the
balance returns to the status
immediately before the error
occurred. Enter the correct
numerical value.

Page 49
ERR W
(Operation error)
The operation used is wrong.
After the error is displayed, the
balance returns to the status
immediately before the error
occurred. At this point, follow
the correct operation.

-
COM ERR
(External input error)
An unrecognizable command
code has been received.

After the error is displayed, the
balance returns to the status
immediately before the error
occurred. At this point, set the
correct command code.

Page 120
OL
- OL
(overload)
The pan is displaced.
The pan supporter caps (TX
series large pan models only)
have come off.


Set the pan correctly on the
balance.
Fit the pan supporter caps (TX
series large pan models only).


Page 27
The weighing capacity has
been exceeded.
 Use the balance within its
weighing capacity.

Page 145
ABORT
(Operation aborted)
The calibration or standard
value setting operation has
been aborted.
 After this is displayed, the
balance returns to the operable
state.

-
WAIT
(Waiting for permission for
the operation)
This message is displayed in
order to avoid unnecessary key
operations.
 After this is displayed, the
balance returns to the operable
state.

-
BUSY
(Load detected)
There was something placed on
the pan when calibration was
started.

Take the item off the pan.
The message will be cleared
automatically and you will be
able to continue calibration.

Page 56
Responding to
Messages
