Shimadzu TXB2201L - Installing the Components; TXB Series

USING THE
BALANCE
USING MORE CONVENIENTLY MAINTENANCE
TROUBLESHOOTING
FOR YOUR
INFORMATION
BEFORE
WEIGHING
27
Continued on next page

TXB Series (large pan model)
TXB***1L, TXB***0L
 TXB Series (small pan model)
TXB**2L, TXB**1L

Balance main body [1]
Menu map sheet [1]
Pan supporter [1]
Pan ring [1]
Pan [1] Balance main body [1] Pan [1]
Pan supporter [1]
Pan ring [1]
Instruction manual [1]
Installing the Components
The procedure for tting the components differs depending on the model of the balance.
TX Series (large pan model) TX***2L
1
Fit the four pan supporter caps.
2
Place the pan on the pan supporters.


Pan supporter capsPan supporter caps
PanPan
