TW/TX Series
Maintenance parts list
Part Name Part Number (P/N) Remarks
Pan (large pan) 321-64587
Pan (small pan) 321-41418-10
Pan (carat) 321-41225 TW/TX series for carat use
Pan with grip 321-41906-01 TW/TX series for carat use
Pan ring 321-41205-11 TW/TX series for carat use
Pan supporter (small pan) 321-64589
Pan supporter (carat) 321-64518 TW/TX series for carat use
Underplate (small pan, carat) 321-64593 TW/TX series, small pan / for carat use
Pan supporter cap (large pan) 321-64591
Glass door ASSY (right) 321-64583-01 TW/TX series, small pan / for carat use
Glass door ASSY (left) 321-64583-02 TW/TX series, small pan / for carat use
Glass door ASSY (top) 321-64581 TW/TX series, small pan / for carat use
Mounting knob for glass door 321-62787-01 TW/TX series, small pan / for carat use
Optional
Part Name Part Number (P/N) Remarks
Electronic printer EP-80 321-62675
Impact dot type, can be used with the
WindowsDirect communication function
Electronic printer EP-90 321-62675-10 The EP-80 with a numeric keypad
RS-232C cable 321-61967 D-Sub 9-pin for DOS/V (length 1.5 m)
USB – serial conversion kit 321-62520-05 With cable (321-61967)
All-surface protective cover
(5 pcs.)
321-64523-10
Specically for TX series large pan
models
Display panel protective cover
(5 pcs.)
321-64522-10 TW/TX series, small pan / for carat use
Level screws 321-64540



