Specications

13
FOR YOUR INFORMATION
TXB Series
Model Name TXB222L TXB422L TXB622L TXB2201L
Weighing capacity 220 g 420 g 620 g 2200 g
Minimum indication 0.01 g 0.1 g
Range of external weights
for calibration
100 - 220 g 100 - 420 g 100 - 620 g 1000 - 2200 g
Repeatability
(standard deviation)
≤ 0.01 g ≤ 0.1 g
Linearity
± 0.01 g ± 0.02 g ± 0.1 g
Response time *
1
2.0 seconds
Ambient temperature 5 - 40 °C
Temperature coefcient for
sensitivity
(10 - 30 °C)
± 15 ppm/°C ± 10 ppm/°C ± 5 ppm/°C ± 15 ppm/°C
Pan size (mm)
f110 f160
Main body dimensions (mm) Approx. 199 (W) × 260 (D) × 77 (H)
Main body weight Approx. 1.5 kg
Display LCD with backlight
Power
requirements
AC adaptor Output 12 V, 1 A
Dry cell
batteries
Six size AA alkaline dry cell batteries
For 40 hours of continuous use (Back light off) *
2
I/O terminal RS-232C, DATA I/O
Model Name TXB4201L TXB6201L TXB621L TXB6200L
Weighing capacity 4200 g 6200 g 620 g 6200 g
Minimum Indication 0.1 g 1 g
Range of external weights
for calibration
1000 - 4200 g 1000 - 6200 g 100 - 620 g 1000 - 6200 g
Repeatability
(standard deviation)
≤ 0.1 g ≤ 1 g
Linearity
± 0.2 g ± 0.1 g ± 1 g
Response time *
1
2.0 seconds
Ambient temperature 5 - 40 °C
Temperature coefcient for
sensitivity
(10 - 30 °C)
± 10 ppm/°C ± 5 ppm/°C ± 20 ppm/°C
Pan size (mm)
f160 f110 f160
Main body dimensions (mm) Approx. 199 (W) × 260 (D) × 77 (H)
Main body weight Approx. 1.5 kg
Display LCD with backlight
Power
requirements
AC adaptor Output 12 V, 1 A
Dry cell
batteries
Six size AA alkaline dry cell batteries
For 40 hours of continuous use (Back light off) *
2
I/O terminal RS-232C, DATA I/O
*1
The response time is a representative value.
*2
When the backlight is lit, the time that the balance can be used continuously is reduced.

