Commissioning
Subject to change without notice
Figure 59 "MODBUS TCP - MODBUS RTU/ASCII gateway settings" dialog for online connections via Ethernet
Button for Ethernet connections
MODBUS TCP - MODBUS RTU/ ASCII gateway settings
Tested MODBUS TCP to MODBUS ASCII/RTU adapter
The connection between FLOWSIC600 and MEPAFLOW600 CBM has been
tested with the "MODBUS TCP to MODBUS ASCII/RTU Converter", Model MES1b
by B&B Electronics. This adapter is shipped with a software, which searches the
network for connectable devices and supplies the user with the IP addresses
found.
Table 18 Interface sets for the connection of the FLOWSIC600 to a network
Description Part Number
MODBUS TCP to MODBUS ASCII/RTU Converter 6044004
