2.3.3 Calculating the actual volume
The operating volume is calculated from the operating volumetric flow rate Q
v, cal
by
integration over time of the measuring intervals.
The total aggregated volume is stored in the operating volume counters for both directions
of flow. The operating volume counters can be reset if the Parameter write lock is
UNLOCKED.
While the system is in "Data invalid" status, the volumes determined are stored in separate
error volume counters. These counters can be reset. Such a reset is recorded in the
Custody logbook [1] together with date and time stamp.
The resolution of aggregated volumes per volume unit [m
3
or ft
3
] is defined in register
#5014 "TotalizerResolution". When reading the volume counters (#5010 to #5013), the
corresponding counter resolution must be considered.
Counter resolution (defaults)
T
s
:Measuring
interval between
two
measurements
V
i
= Q
v, cal
· T
s
Reg. Volume Counter Abbreviation
#5010 Volume at flowing conditions (forward) + Vf
#5012 Volume at flowing conditions (reverse) - Vf
Reg. Volume Counter Abbreviation
#5011 Error volume at flowing conditions (forward) + Ef
#5013 Error volume at flowing conditions (reverse) - Ef
V = Volume register value [m³]· [m³]
TotalizerResolution[1/m³]
1000
Table 1
Metric Units
Nominal pipe size
Register #5014
[1/m³]
Resulting
resolution [m³]
DN 50 (NPS 2)
10 0.01DN 80 (NPS 3)
DN 100 (NPS 4)
DN 150 (NPS 6)
100 0.1
DN 200 (NPS 8)
DN 250 (NPS 10)
DN 300 (NPS 12)
DN 350 (NPS 14)
DN 400 (NPS 16)
DN 450 (NPS 18)
1,000 1.0DN 500 (NPS 20)
DN 600 (NPS 24)
NPS28 - NPS48 10,000 10
