9.3.4 Data editing in Configuration Mode
In configuration parameters which are relevant to the commissioning or operation of the
meter can be modified. If the Parameter write lock is LOCKED, it must be set to the
"UNLOCKED" before parameter modification.
Navigate to the parameter and use the ENTER function to begin editing.
Options depending on the type of data:
● Integer:0, 1, 2, 3, 4, 5, 6, 7, 8, 9, sign
● Floating point:0, 1, 2, 3, 4, 5, 6, 7, 8, 9, space, decimal point, sign
● List of registers:List of all registers (which are plausible for this parameter)
Example: Switching the meter to Configuration Mode and editing a parameter, e.g. the
impulse factor.
Action Buttons Display
Standard display -
+V 34569870 m3
-V 0 m3
Enter menu ENTER
Operation Mode
Operation
Edit parameter "Operation Mode" ENTER
Configuration?
OK Cancel
Confirm change to "Maintenance
Mode"
ENTER –> Change mode
Configuration?
Success!
Scroll through the menu structure to
the parameter you want to edit
(ENTER, STEP, DATA)
In this example, the impulse factor is
edited
Impulse factor
115/m3
Select the parameter ENTER
Impulse factor
115
Move cursor to the digit that you want
to change
1 * STEP
Impulse factor
11
Put in edit mode 2 * DATA
Impulse factor
115
Enter desired value x * DATA
Impulse factor
110
Confirm new value ENTER
Impulse factor
110/m3
Return to standard display 3 x CE/C
+V 34569870 m3
-V 0 m3
