Product Description
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 39
Subject to change without notice
2.6.3 Output of pulse signals and status information
* The meter can be configured to output a fixed frequency if the meter has the status
"Data invalid". The frequency to be output in this case can be configured (0-6 kHz) in Reg.
#3034 "ErrorFreq".
** Default setting on delivery.
*** Optional setting on customer request.
The default setting for "Check request", "Configuration" and "Data invalid" is "normally
closed".
NOTICE: TYPE APPROVAL
Pulse output signals can be customized as shown in the following table.
Table 6 Pulse output
Output signal / LCD / port
Signal behavior
Measurement status Check request status Configuration Mode Data invalid*
Pulse
output
signals
Inverted with error
signal **
Phase
shift
90 ° ***
Positive
flow rate
Negative
flow rate
Separate
outputs
for reach
direction
Positive
flow rate
Negative
flow rate
Single pulse output
***
