SICK FLOWSIC600 Technical Information

Flow Calibration
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 67
Subject to change without notice
3.2.1 Recommended test flow rates
The recommended number and position of test points are provided in OIML and AGA
documents and are summarized in the table below. Alternatively they may be defined
individually by the customer.
% values in table relate to Q
max
Test points according to OIML R137-1 Test points
according to
A.G.A. Report
No.9
Test points
according to
MID Directive
2004/22/EC
Measuring range (turn down)
1:20 1:30 1:50 1:50 All ranges All ranges
- - - Q
min
- - 2% - 2.5% Qmin
- 3% - 3% - -
5% 5% 5% 5% 5% 5%
10% 10% - - 10% 10%
- - 15% 15% - -
25% 25% 25% 25% 25% 25%
40% 40% 40% 40% 50% 40%
70% 70% 70% 70% 75% 70%
100% 100% 100% 100% 100% 100%
