SICK FLOWSIC600 Technical Information

Appendix
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 213
Subject to change without notice
● Any flow rates given above are also valid in the bidirectional mode.
● G-classes marked with an asterisk (*) must only be used in configuration No. 2 (see
 pg. 99, 4.2.2).
● G-classes marked with an (E) have an extended max. flow rate (max. flow velocity v
max
=
36 m/s) related to commonly established turbine meter G-classes.
● The transition flow Q
t
is based on the flow range the meter is designed for according to
the main plate. It is:
● Higher values for Q
min
and lower values for Q
max
are admissible provided that
Q
min
0.05 Q
max
.
● Another meter factor is admissible if the frequency at the pulse output is selected
<6
kHz for 1.2 Q
max
.
DN950
(38“)
G16000 1300 25000 288
G25000 1300 40000 180
G40000 800 1300 65000 111
DN 1000
(40")
G16000 1300 25000 288
G25000 1300 40000 180
G40000 650 800 1300 65000 111
- for a flow range of 1:20 Q
t
=0.20 Q
max
and
- for a flow range of 1:30 Q
t
=0.15 Q
max
and
- for a flow range of

1:50 Q
t
=0.10 Q
max
Meter
size
Meter size
Measuring range (Qmin [m³/h])
Max. flow
rate Qmax
[m³/h]
Meter
factor
[pulses/
m³]
1:100 1:80 1:50 1:30 1:20
