Weights and dimensions
Figure 98 Dimensioned drawing
A
C
D
206
A
C
B
D
Models for nominal sizes from 16"/DN 400 (forged)
* Dimension F must be
specified by the customer, as it
depends on the internal pipe
diameter at the installation
location.(see
 pg. 220, Table 30
or type-code)
Longitudinal section for nominal sizes up to 48"/DN 1200
Models for nominal sizes of 3"/DN 80 up to 14"/DN 350 (cast)
E
F*
10°
