Appendix
Subject to change without notice
Table 30 Inner pipe diameter
Nominal pipe
size
Pipe dimensions in accordance with ANSI B36.10M - 1985 DIN 2633 DIN 2636 DIN 2637
SC20 SC30 SC40 SC60 SC80 PN16 PN64 PN100
2" 52.5 49.3
DN 50 54.5 54.5 54.5
3" 77.9 73.7
DN 80 82.5 81.5 80.9
4" 102.3 97.2
DN 100 107.1 106.3 104.3
6" 154.1 146.3
DN 150 159.3 157.1 154.1
8" 206.4 205 202.7 198.5 193.7
DN 200 206.5 204.9 199.1
10" 260.4 257.5 254.5 247.7 242.9
DN 250 260.4 255.4 248.0
12" 311.2 307.1 303.2 295.3 288.9
DN 300 309.7 301.9 295.5
14" 339.8 336.6 333.3 325.4 317.5
DN 350 339.6 343.0 336.0
16" 390.6 387.4 381.0 373.1 363.5
DN 400 390.4 378
18" 441.4 434.9 428.7 419.1 409.5
DN 450
20" 489.0 482.6 477.8 466.8 455.6
DN 500 492.0
24" 590.6 581.1 574.6 560.4 547.7
DN 600 592.4
