Appendix
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 223
Subject to change without notice
+Vo 141145m3
-Vo 0m3
Display of the Total volume counter at flowing conditions
forward (+Vo) and reverse (-Vo).
VC readings
EVC readings menu. Enter the menu with the ENTER function to
view the EVC readings.
+VB Nm3
-VB Nm3
Display of the Total volume counter at base conditions forward
(+VB) and reverse (-VB).
+M t
-M t
Display of the Mass counter forward (+M) and reverse (-M).
p C
T bar
Display of the live values of pressure (p) and temperature (T) as
written from a sensor or as found in Reg. #7040 "Temperature
(fixed)" and Reg. #7041 "Pressure (fixed)".
+M t/h
Display of the Mass Flow (Mf).
Battery
Charge 100%
Display of battery charge.
Device state
E:0 W:1 I:2
Display of the current device state. The number of active
Errors, Warnings and Information is displayed. To view the
messages enter the menu with the ENTER function.
Error 3003:
Reading invalid
Currently active error, warning or information. The number of
the message is displayed in the first line (1xxx=Information,
2xxx=Warning, 3xxx=Error). See table in Section
ď‚®
9.4.1. Use
the STEP and the DATA button to navigate through the
messages.
Use the ENTER function to go from the standard
display to the main menu.
Main Menu Submenu Submenu Notes
The main menu provides menus and submenus for topically
structured information and user operations.
Operation Mode
Measurement
Display of the current operating mode ("Operation" or
"Configuration"). Use the ENTER function to switch the mode.
Configuration
OK Cancel
Confirmation dialog for switching to the indicated operating
mode. Use the ENTER function to confirm or the C/CE button
to cancel the dialog. Event is logged in Logbook1.
FLOWSIC600
Settings
"Parameter change" menu with submenus for editing the
system configuration at commissioning and parameterization.
Parameters can only be changed in "Configuration" mode.
Standard Display Submenu Notes
To Next Page
