SICK FLOWSIC600 Technical Information

Appendix
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 253
Subject to change without notice
Figure 117 Sealing plan, part 2 (cast version)
Side view, rear
Front viewSide view, front
Side view, rear
Detail X
Side view, front
* Seal - adhesive tape, minimum of two seals per
capping, screws flush with surface
1 Placement of seals, SPU cover - front and rear 2 Placement of seals, capping - front and rear
1
2
1
1
1
1
1
2
2*
2
2
DN100/NPS4”
DN80/NPS3”
For DN100, NPS4” from manufacturing year 2004 and DN80, NPS3”
