Appendix
FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG 255
Subject to change without notice
Figure 119 Sealing plan, part 4
alternatively
1
3
2
1 Safety hoop
2 Cross pin screw M4 DIN404
3 Seal place for front- and back cover
1
3
2
