42 FLOWSIC600 · Technical Information · 8010125 V 4.0 · © SICK AG
Product Description
Subject to change without notice
Table 8 System warnings in the User Warnings
Monitored
measurement
Configurable User
Warning
Parameters
Default value Notes
Default
activation
state
1
Profile factor
Profile factor
valid value
2
1.11
3
The profile factor represents the path velocity ratios
of inner to outer paths. A change of the profile value
may be caused by contamination, blockages or
deposits in the line that change the shape of the flow
profile.
Off
Profile factor
range
2
5%
3
Symmetry
Symmetry
valid value
2
1.00
3
The symmetry represents the path velocity ratios of
upper to lower paths. A change of the symmetry
value may be caused by contamination, blockages or
deposits in the line that change the symmetry of the
flow profile.
Off
Symmetry
range
2
5%
3
Speed of sound
(SOS) - deviation
from theoretical
SOS
Theoretical
SOS deviation
0.3%
Optionally, a theoretical SOS calculated for the
current gas composition, temperature and pressure
can be written to the meter (e.g. from a flow
computer). If the current measured SOS deviates
from the theoretical SOS, a user warning is
generated.
Off
High gas velocity VOG limit 45 m/s
If the current Avg. Velocity of Gas exceeds the value
"VOG limit", a User Warning is generated.
Off
Power supply
(low input
voltage)
Input voltage
warning
12000mV
If the power supply voltage drops below the value
"Input voltage warning", a User Warning is
generated.
Off
Monitored event
Configurable User Warning
Parameters
Notes
Default
activation
state
1
A Logbook is full
of
unacknowledged
entries
Logbook full of unack.
entries
If one of the logbooks is full of unacknowledged
entries, a User Warning is generated.
Off
Meter is in
Configuration
Mode
Warning at Configuration
Mode
If the meter is in Configuration Mode, a User Warning
is generated.
Off
Battery lifespan
Warning if battery lifespan is
low
If the remaining battery lifespan is less than 15%, a
User Warning is generated.
On
1
User Warnings must be activated to become effective on the warning output.
2
These User Warning limits are only monitored, as long as certain preconditions are met. The VOG must be above the value set in "Min. VOG for warnings"
and the SOS must be relatively stable (change in %/s must be below the value set in "SOS profile rising").
3
The default value for these warning parameters can only be applied for a fully developed and symmetrical flow profile e.g. with a flow conditioner. The
values should be adapted to the specific application
v2 v3+
v1 v4+
-------------------=
v1 v2+
v3 v4+
-------------------=
-
