Annex
14.2 Checklist for the manufacturer

Checklist for the manufacturer/installer for the installation of electro-sensitive protective equipment (ESPE)
Details about the points listed below must be present at least during initial commissioning — they are, however,
dependent on the respective application, the specifications of which are to be controlled by the manufacturer/installer.
This checklist should be retained and kept with the machine documentation to serve as reference during recurring
tests.
1. Have the safety rules and regulations been observed in compliance with the directives/standards applicable to the
machine?
Yes " No "
2. Are the applied directives and standards listed in the declaration of conformity? Yes " No "
3. Does the protective device comply with the required PL/SIL claim limit and PFHd in accordance with
EN ISO 13849-1/EN 62061 and the required type in accordance with IEC 61496-1?
Yes " No "
4. Is the access to the hazardous area/hazardous point only possible through the protective field of the ESPE? Yes " No "
5. Have appropriate measures been taken to protect (mechanical protection) or monitor (protective devices) any
persons or objects in the hazardous area when protecting a hazardous area or hazardous point, and have these
devices been secured or locked to prevent their removal?
Yes " No "
6. Are additional mechanical protective measures fitted and secured against manipulation which prevent reaching
under, over or around the ESPE?
Yes " No "
7. Has the maximum stopping and/or stopping/run-down time of the machine been measured, specified and
documented (at the machine and/or in the machine documentation)?
Yes " No "
8. Has the ESPE been mounted such that the required minimum distance from the nearest hazardous point has been
achieved?
Yes " No "
9. Are the ESPE devices properly mounted and secured against manipulation after adjustment? Yes " No "
10. Are the required protective measures against electric shock in effect (protection class)? Yes " No "
11. Is the control switch for resetting the protective device (ESPE) or restarting the machine present and correctly
installed?
Yes " No "
12. Are the outputs of the ESPE (OSSD) integrated according to required PL/SILCL compliant with
EN ISO 1384991/EN 62061 and does the integration correspond to the comply with the circuit diagrams?
Yes " No "
13. Has the protective function been checked in compliance with the test notes of this documentation? Yes " No "
14. Are the specified protective functions effective at every operating mode that can be set? Yes " No "
15. Are the switching elements activated by the ESPE, e.g. contactors, valves, monitored? Yes " No "
16. Is the ESPE effective over the entire period of the dangerous state? Yes " No "
17. Once initiated, will a dangerous state be stopped when switching the ESPE on or off and when changing the
operating mode, or when switching to another protective device?
Yes " No "
18. Has the information label for the daily check been attached so that it is easily visible for the operator? Yes " No "
This checklist does not replace the initial commissioning, nor the regular inspection by qualified safety personnel.
