Operating instructions Chapter 4
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 33
Subject to change without notice
Configurable functions
4.3 Application
With the help of the CDS you can configure the S300 for the required application. Depen-
ding on whether you select a stationary or a mobile application, different configuration
options are available:
Mobile applications Stationary applications
Resolution
30 mm (hand detection with smaller
protective field size)
40 mm (hand detection with larger
protective field size)
50 mm (leg detection with smaller
protective field size)
70 mm (leg detection with larger
protective field size)
8)
30 mm (hand detection with smaller
protective field size)
40 mm (hand detection with larger
protective field size)
50 mm (leg detection with smaller
protective field size)
70 mm (leg detection with larger
protective field size)
150 mm
9)
(body detection)
Manipulation prevention
The safety laser scanner checks whether in any 90° segment all measured values
correspond to the maximum distance value that can be measured.
If this is the case, the S300 shuts down
after 2 hours and signals .
If this the case, the S300 shuts down
after 5 seconds and signals .
8)
In mobile applications a resolution of only 70 mm is required for leg detection, as a coarser resolution is
adequate for the detection of a human leg due to the movement of the vehicle.
9)
Can only be configured with the Long Range variant with 3 m scanning range.
Tab.
9
:
Comparison of mobile
and stationary applications
