Operating instructions Chapter 12
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 117
Subject to change without notice
Technical specifications
12.2 OSSD response times
The total response time of your application is dependent on …
the basic response time of the S300.
the multiple sampling set.
the OSSDs used.
How to calculate the total response time T
S
:
T
S
= t
B
+ T
M
FA
+ T
E
FIO
Where …
t
B
= Basic response time = 80 ms
T
M
FA
= Supplement due to multiple sampling > 2
T
EFIO
= Supplement for the usage of external OSSDs via EFI
Multiple sampling
On the S300 at least double multiple sampling is always set. For a multiple sampling of 3
or higher you must add a supplement of 80 ms to the basic response time.
Multiple sampling Supplement Basic response time + supplement
2 times (basic setting) 0 ms 80 ms
3 times 40 ms 120 ms
4 times 80 ms 160 ms
5 times 120 ms 200 ms
6 times 160 ms 240 ms
7 times 200 ms 280 ms
8 times 240 ms 320 ms
9 times 280 ms 360 ms
10 times 320 ms 400 ms
11 times 360 ms 440 ms
12 times 400 ms 480 ms
13 times 440 ms 520 ms
14 times 480 ms 560 ms
15 times 520 ms 600 ms
16 times 560 ms 640 ms
External OSSDs
If you use the OSSDs on another device via EFI as external output signal switching devices
(for example with two S300 connected together), the response time increases by 20 ms in
each case.
Tab.
34
:
Supplements for
multiple sampling
