Operating instructions Chapter 3
S300
8010948/YY96/2016-02-17 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 19
Subject to change without notice
Product description
3.2.3 Monitoring cases
Depending on the variant used (see section “Functions of the S300 variants” on page 20)
up to 32 monitoring cases can be defined and selected during operation using local static
o
r dynamic control inputs or via EFI. In this way process-dependent hazardous area pro-
tection or velocity-dependent vehicle monitoring is possible for example.
Fig.
4
:
S300
Remote with
two monitoring cases on an
AGV
Field set 2 with larger
protective and warning fields
Field set 1
Monitoring case 2
High velocity
Monitoring case 1
Low velocity

SICK S300 Specifications

General

Protection Class	IP65
Resolution	30 mm
Interface	RS-422, Ethernet
Power Supply	24 V DC
Operating Temperature	0 °C ... +50 °C
