Chapter 14 Operating instructions
S300
142 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010948/YY96/2016-02-17
Subject to change without notice
Annex
The S300 has five universal I/O connections. These connections can be configured as
inputs (e.g. for stand-by, EDM or reset) or as outputs (e.g. for device error, contamination
or second warning field).
The warning field is a field with a radius of up to 8 m (see section 12.1 “Characteristics” on
page 116). Using this field larger areas can be controlled and simple switching functions
(e.g. warning functions) triggered. The warning field is not allowed to be used for tasks
related to personnel protection.
Glossar (Ende)
Universal I/O
Warning field
