Table 43: MLG-2 data sheet - inputs
Input Voltage 0 V … V
S
Logic level switching points
•
HIGH
•
LOW
•
> 15 V
•
< 5 V
The pulse duration must be greater than the
response time: see "Response time", page 89
Outputs
Table 44: MLG-2 data sheet - outputs
Switching mode Push-pull
Logic level switching points
•
HIGH
•
LOW
•
V
S
– 3 V
•
< 3 V
Maximum output current per output ≤ 100 mA
Output load per output
•
Capacitive
•
Inductive
•
100 nF
•
1 H
Load resistance for analog output 4 …
20 mA
< 600 W
Response time see "Response time", page 89
Ethernet interface
Table 45: MLG-2 data sheet - Ethernet interface
Data transmission rate 100 Mbit/s
Default IP address 192.168.200.100
Subnet mask 255.255.255.000
Protocol TCP/IP
Maximum length of cable According to IEE802.3 (typ. 100 m)
RS-485 interface
Table 46: MLG-2 data sheet - RS-485 interface
Data transmission rate 1200, 2400, 4800, 9600, 19200, 38400, 57600,
115200, 230400, 460800, 500000, 921600 bit/s
IO-Link interface
Table 47: MLG-2 data sheet - IO-Link interface
Version 1.1
Data transmission rate COM3: 230.4 kbit/s
Maximum length of cable 20 m
Cycle time 14 ms
Vendor ID 26
Device ID 8389167
Process data 32 Byte (TYPE_2_V)
1
1
For an IO-Link master with V1.0, reverts to interleaved mode (consisting of TYPE_1_1 (process data) and
TYPE_1_2 (on-request data)).
Technical measurement data
Table 48: MLG-2 data sheet – Technical measurement specifications
Light sender
LED, infrared
TECHNICAL DATA 16
8024643/2019-09-02 | SICK O P E R A T I N G I N S T R U C T I O N | MLG-2 WebChecker
87
Subject to change without notice
