Table 59: Part numbers for connecting cable with female connector
Type Head A connec‐
tion type
Head B connec‐
tion type
Connecting cable Part no.
DOL-1205-G05MAC Female connec‐
tor, M12,
5-pin, straight,
screened
Cable, flying
leads
5 m, 5-wire 6036384
DOL-1205-G02M Female connec‐
tor, M12,
5-pin, straight,
unscreened
Cable, flying
leads
2 m, 5-wire 6008899
DOL-1205-G05M 5 m, 5-wire 6009868
DOL-1205-G10M 10 m, 5-wire 6010544
DOL-1205-G15M 15 m, 5-wire 6029215
DOL-1208-G02MF Female connec‐
tor, M12,
8-pin, straight,
screened
Cable, flying
leads
2 m, 8-wire 6020663
DOL-1208-G05MF 5 m, 8-wire 6020664
DOL-1208-G10MF 10 m, 8-wire 6048434
Table 60: Female and male connector part numbers
Type Head A connection type Head B connection type Part no.
DOS-1205-G Female connector, M12, 5-
pin,
straight, unscreened
Screw terminals 6009719
DOS-1208-G Female connector, M12, 8-
pin,
straight, unscreened
Screw terminals 6028422
DOS-1208-GA Female connector, M12, 8-
pin,
straight, screened
Screw terminals 6028369
STE-1205-G Male connector, M12, 5-
pin,
straight, unscreened
Screw terminals 6022083
STE-1208-GA Male connector, M12, 8-
pin,
straight, screened
Screw terminals 6028370
Table 61: Part numbers for connecting cable with male/female connector
Type Head A connec‐
tion type
Head B connec‐
tion type
Connecting cable Part no.
DSL-1205-G01MC Male connector,
M12,
5-pin, straight,
unscreened
Female connec‐
tor, M12, 5-pin,
straight
1 m, 5-wire 6029280
DSL-1205-G02MC 2 m, 5-wire 6025931
DSL-1205-G05MC 5 m, 5-wire 6029282
DSL-1205-G10MC 10 m, 5-wire 6038954
DSL-1208-G01MAC Female connec‐
tor, M12,
8-pin, straight,
screened
Male connector,
M12, 8-pin,
straight
1 m, 8-wire 6026625
DSL-1208-G02MAC 2 m, 8-wire 6030121
DSL-1208-G05MAC 5 m, 8-wire 6032325
DSL-1208-G10MAC 10 m, 8-wire 6034901
Table 62: Ethernet connecting cable part numbers
Type
Head A connec‐
tion type
Head B connec‐
tion type
Connecting cable Part no.
SSL-1204-G02ME Male connector,
M12,
4-pin, D-coded,
screened
Male connector,
M12,
4-pin, D-coded
2 m, 4-wire 6034420
SSL-1204-G05ME 5 m, 4-wire 6034422
ACCESSORIES 17
8024643/2019-09-02 | SICK O P E R A T I N G I N S T R U C T I O N | MLG-2 WebChecker
97
