7SR11 & 7SR12 Settings & Instruments Guide
©2017 Siemens Protection Devices Limited Chapter 2 Page 13 of 20
Max 0.00V
Min 0.00V
Mean 0.00V
Displays the Voltage demand based on Vab.
Max 0.00V
Min 0.00V
Mean 0.00V
Displays the Voltage demand based on Vbc.
Max 0.00V
Min 0.00V
Mean 0.00V
Displays the Voltage demand based on Vca.
Max 0.00W
Min 0.00W
Mean 0.00W
Displays the Active Power demand.
Max 0.00VAr
Min 0.00VAr
Mean 0.00VAr
Displays the Reactive Power demand.
Max 0.00VA
Min 0.00VA
Mean 0.00VA
Displays the Apparent Power demand.
Max 0.000Hz
Min 0.000Hz
Mean 0.000Hz
Displays the Frequency demand.
MISCELLANEOUS METERS
→to view
This is the sub-group that includes indication such as the relays
time and date, the amount of fault and waveform records stored in
the relay TEST/RESET ► allows access to this sub-group
Count 0
Target 100
Count of configurable type of Relay starts
Time 22:41:44
Waveform Recs 0
Fault Recs 0
This meter displays the date and time and the number of Fault
records and Event records stored in the relay
Data Log Recs 0
Setting Group 1
BINARY INPUT METERS
→to view
This is the sub-group that includes all the meters that are
associated with the Binary inputs TEST/RESET ► allows access
to this sub-group
BI 1-6 ---- --
Displays the state of DC binary inputs 1 to 6 (The number of binary
inputs may vary depending on model)
BINARY OUTPUT METERS
→to view
This is the sub-group that includes all the meters that are
associated with the Binary Outputs TEST/RESET ► allows access
to this sub-group
BO 1-8 ---- ----
Displays the state of DC binary Outputs 1 to 8. (The number of
binary outputs may vary depending on model)
VIRTUAL METERS
→to view
This is the sub-group that shows the state of the virtual status
inputs in the relay TEST/RESET ► allows access to this sub-
group
V 1-8 ---- ----
Displays the state of Virtual Outputs 1 to 8 (The number of virtual
To Next Page
