7SR11 & 7SR12 Settings & Instruments Guide
Chapter 2 Page 14 of 20 ©2017 Siemens Protection Devices Limited
inputs will vary depending on model)
COMMUNICATION METERS
→to view
This is the sub-group that includes all the meters that are
associated with Communications ports TEST/RESET ► allows
access to this sub-group
COM1 X
COM2
Displays which com ports are currently active
COM1 TRAFFIC
COM1 Tx1 0
COM1 Rx1 Error 0
COM1 Rx1 0
Displays data traffic on Communications Port 1
COM2 TRAFFIC
COM2 Tx1 0
COM2 Rx1 Error 0
COM2 Rx1 0
Displays data traffic on Communications Port 2
Version : EN100 Version Info
Part# BF1111111111
Displays EN100 information
Mac 00000000
IP 000.000.000.000
NM 255.255.255.000
Displays EN100 network information
EN100 NTP info:
EN100 Link ½ status info:
EN100 Rx/Tx Count
Displays further EN100 61850 information
En100 Rx/Tx 10s
CPU Load %
EN100 Info Meters : 1-n
Displays further EN100 61850 information
QUICK LOGIC METERS
→to view
This is the sub-group that includes all the meters that are
associated with QuickLogic Equations TEST/RESET ► allows
access to this sub-group
E 1-4 ----
E1 Equation
EQN =0
TMR 0-0 =0
CNT 0-1 =0
E2 Equation
EQN =0
TMR 0-0 =0
CNT 0-1 =0
E3 Equation
EQN =0
TMR 0-0 =0
CNT 0-1 =0
E4 Equation
EQN =0
TMR 0-0 =0
CNT 0-1 =0
