Siemens 7SR12 Argus User Manual

Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 17 of 84
FUN INF Description ASDU COT
183 24 51N-3 2 SE, GI
183 25 50N-3 2 SE, GI
183 26 51G-3 2 SE, GI
183 27 50G-3 2 SE, GI
183 28 51-4 2 SE, GI
183 29 50-4 2 SE, GI
183 30 51N-4 2 SE, GI
183 31 50N-4 2 SE, GI
183 32 51G-4 2 SE, GI
183 33 50G-4 2 SE, GI
183 34 50BF Stage 2 2 SE, GI
183 35 49-Alarm 2 SE, GI
183 36 49-Trip 2 SE, GI
183 40 60 CTS 2 SE, GI
183 50 46IT 2 SE, GI
183 51 46DT 2 SE, GI
183 52 64H 2 SE, GI
2 SE, GI
183 53 E/F Out
20 Ack, Nak
183 56 50BF Stage 1 2 SE, GI
183 60 47-1 2 SE, GI
183 61 47-2 2 SE, GI
183 62 37-1 2 SE, GI
183 63 37-2 2 SE, GI
183 64 37G-1 2 SE, GI
183 65 37G-2 2 SE, GI
183 70 46BC 2 SE, GI
183 81 27/59-1 2 SE, GI
183 82 27/59-2 2 SE, GI
183 83 27/59-3 2 SE, GI
183 84 27/59-4 2 SE, GI
183 85 59NIT 2 SE, GI
183 86 59NDT 2 SE, GI
183 90 81-1 2 SE, GI
183 91 81-2 2 SE, GI
183 92 81-3 2 SE, GI
183 93 81-4 2 SE, GI
183 96 81HBL2 1 SE, GI
183 100 CB Alarm 1 SE, GI
183 101 Trip Circuit Fail 1 2 SE, GI
183 102 Trip Circuit Fail 2 2 SE, GI
183 103 Trip Circuit Fail 3 2 SE, GI
183 114 Close CB Failed 1 SE, GI
183 115 Open CB Failed 1 SE, GI
183 116 Reclaim 1 SE, GI
183 117 Lockout 1 SE, GI
183 119 Successful DAR Close 1 SE
183 120 Successful Man Close 1 SE
