7SR120 Technical Manual
Chapter 4 - Page 18 of 84 © 2017 Siemens Protection Devices Limited
FUN INF Description ASDU COT
1 SE, GI
183 121 HotLine Working
20 Ack, Nak
1 SE, GI
183 122 Inst Protection Out
20 Ack, Nak
183 123 CB Total Trip Count 1 SE, GI
183 124 CB Delta Trip Count 1 SE, GI
183 125 CB Count To AR Block 1 SE, GI
1 SE
183 126 Reset CB Total Trip Count
20 Ack, Nak
1 SE
183 127 Reset CB Delta Trip Count
20 Ack, Nak
1 SE
183 128 Reset CB Count To AR Block
20 Ack, Nak
183 129 I^2t CB Wear 1 SE, GI
1 SE
183 130 Reset I^2t CB Wear
20 Ack, Nak
183 131 79 AR In progress 1 SE, GI
183 132 CB Frequent Ops Count 1 SE, GI
1 SE
183 133 Reset CB Frequent Ops Count
20 Ack, Nak
183 137 CB on by auto reclose 1 SE, GI
183 140 Cold Load Active 1 SE, GI
183 141 P/F Inst Protection Inhibited 1 SE, GI
183 142 E/F Inst Protection Inhibited 1 SE, GI
183 144 Ext Inst Protection Inhibited 1 SE, GI
183 163 Trip Time Alarm 1 SE
183 164 Close Circuit Fail 1 2 SE, GI
183 165 Close Circuit Fail 2 2 SE, GI
183 166 Close Circuit Fail 3 2 SE, GI
183 167 Close Circuit Fail 2 SE, GI
183 171 60 CTS-I 2 SE, GI
183 172 Act Energy Exp 4 SE
183 173 Act Energy Imp 4 SE
183 174 React Energy Exp 4 SE
183 175 React Energy Imp 4 SE
1 SE
183 176 Reset Energy Meters
20 Ack, Nak
183 177 Active Exp Meter Reset 1 SE
183 178 Active Imp Meter Reset 1 SE
183 179 Reactive Exp Meter Reset 1 SE
183 180 Reactive Imp Meter Reset 1 SE
183 181 CB Total Trip Count 4 SE
183 182 CB Delta Trip Count 4 SE
183 183 CB Count To AR Block 4 SE
183 184 CB Freq Ops Count 4 SE
183 222 37-PhA 2 SE, GI
183 223 37-PhB 2 SE, GI
183 224 37-PhC 2 SE, GI
183 231 50BF-PhA 2 SE, GI
