FUN INF Description ASDU COT
186 14 AFD Zone 5 1 SE, GI
186 15 AFD Zone 6 Flash 1 SE, GI
186 16 AFD Zone 6 1 SE, GI
186 17 AFD Zone1 Count 4 SE
186 18 AFD Zone2 Count 4 SE
186 19 AFD Zone3 Count 4 SE
186 20 AFD Zone4 Count 4 SE
186 21 AFD Zone5 Count 4 SE
186 22 AFD Zone6 Count 4 SE
1 SE
200 1 CB 1
20 Ack, Nak
200 6 CB 1 Opened 1 SE, GI
200 7 CB 1 Closed 1 SE, GI
1 SE, GI
200 150 User SP Command 1
20 Ack, Nak
1 SE, GI
200 151 User SP Command 2
20 Ack, Nak
1 SE, GI
200 152 User SP Command 3
20 Ack, Nak
1 SE, GI
200 153 User SP Command 4
20 Ack, Nak
1 SE, GI
200 154 User SP Command 5
20 Ack, Nak
1 SE, GI
200 155 User SP Command 6
20 Ack, Nak
1 SE, GI
200 156 User SP Command 7
20 Ack, Nak
1 SE, GI
200 157 User SP Command 8
20 Ack, Nak
1 SE
200 158 User DP Command 1
20 Ack, Nak
1 SE
200 159 User DP Command 2
20 Ack, Nak
1 SE
200 160 User DP Command 3
20 Ack, Nak
1 SE
200 161 User DP Command 4
20 Ack, Nak
1 SE
200 162 User DP Command 5
20 Ack, Nak
1 SE
200 163 User DP Command 6
20 Ack, Nak
1 SE
200 164 User DP Command 7
20 Ack, Nak
1 SE
200 165 User DP Command 8
20 Ack, Nak
1 SE
200 200 CB 1 Trip & Reclose
20 Ack, Nak
1 SE
200 201 CB 1 Trip & Lockout
20 Ack, Nak
