Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 21 of 84
FUN INF Description ASDU COT
200 255 Blocked By Interlocking 1 SE, GI
60 4 Remote Mode 0 SE, GI
60 5 Out Of Service Mode 0 SE, GI
60 6 Local Mode 0 SE, GI
60 7 Local & Remote 0 SE, GI
60 12 Control Received 0 SE
60 13 Command Received 0 SE
60 128 Cold Start 0 SE
60 129 Warm Start 0 SE
60 130 Re-Start 0 SE
60 131 Expected Restart 0 SE, GI
60 132 Unexpected Restart 0 SE, GI
60 133 Reset Start Count 0 SE
60 135 Trigger Storage 0 SE
60 136 Clear Waveform Records 0 SE
60 137 Clear Fault Records 0 SE
60 138 Clear Event Records 0 SE
60 140 Demand metering reset 0 SE
60 170 General Alarm 1 0 SE, GI
60 171 General Alarm 2 0 SE, GI
60 172 General Alarm 3 0 SE, GI
60 173 General Alarm 4 0 SE, GI
60 174 General Alarm 5 0 SE, GI
60 175 General Alarm 6 0 SE, GI
60 182 Quick Logic E1 0 SE, GI
60 183 Quick Logic E2 0 SE, GI
60 184 Quick Logic E3 0 SE, GI
60 185 Quick Logic E4 0 SE, GI
70 5 Binary Input 5 0 SE, GI
70 6 Binary Input 6 0 SE, GI
75 1 Virtual Input 1 0 SE, GI
75 2 Virtual Input 2 0 SE, GI
75 3 Virtual Input 3 0 SE, GI
75 4 Virtual Input 4 0 SE, GI
75 5 Virtual Input 5 0 SE, GI
75 6 Virtual Input 6 0 SE, GI
75 7 Virtual Input 7 0 SE, GI
75 8 Virtual Input 8 0 SE, GI
80 1 Binary Output 1 0 SE, GI
80 2 Binary Output 2 0 SE, GI
80 3 Binary Output 3 0 SE, GI
80 4 Binary Output 4 0 SE, GI
80 5 Binary Output 5 0 SE, GI
80 6 Binary Output 6 0 SE, GI
80 7 Binary Output 7 0 SE, GI
80 8 Binary Output 8 0 SE, GI
90 1 LED 1 0 SE, GI
90 2 LED 2 0 SE, GI
