7SR120 Technical Manual
Chapter 4 - Page 22 of 84 © 2017 Siemens Protection Devices Limited
FUN INF Description ASDU COT
90 3 LED 3 0 SE, GI
90 4 LED 4 0 SE, GI
90 5 LED 5 0 SE, GI
90 6 LED 6 0 SE, GI
90 7 LED 7 0 SE, GI
90 8 LED 8 0 SE, GI
90 9 LED 9 0 SE, GI
91 1 LED PU 1 0 SE, GI
91 2 LED PU 2 0 SE, GI
91 3 LED PU 3 0 SE, GI
91 4 LED PU 4 0 SE, GI
91 5 LED PU 5 0 SE, GI
91 6 LED PU 6 0 SE, GI
91 7 LED PU 7 0 SE, GI
91 8 LED PU 8 0 SE, GI
91 9 LED PU 9 0 SE, GI
160 2 Reset FCB 0 SE
160 3 Reset CU 0 SE
160 4 Start/Restart 0 SE
160 5 Power On 0 SE, GI
160 16 Auto-reclose active 0 SE, GI
160 19 LED Reset 0 SE
160 22 Settings changed 0 SE
160 23 Setting G1 selected 0 SE, GI
160 24 Setting G2 selected 0 SE, GI
160 25 Setting G3 selected 0 SE, GI
160 26 Setting G4 selected 0 SE, GI
160 27 Binary Input 1 0 SE, GI
160 28 Binary Input 2 0 SE, GI
160 29 Binary Input 3 0 SE, GI
160 30 Binary Input 4 0 SE, GI
160 36 Trip Circuit Fail 0 SE, GI
160 38 VT Fuse Failure 0 SE, GI
160 51 Earth Fault Forward/Line 0 SE, GI
160 52 Earth Fault Reverse/Busbar 0 SE, GI
160 64 Start/Pick-up L1 0 SE, GI
160 65 Start/Pick-up L2 0 SE, GI
160 66 Start/Pick-up L3 0 SE, GI
160 67 Start/Pick-up N 0 SE, GI
160 68 General Trip 0 SE
160 69 Trip L1 0 SE
160 70 Trip L2 0 SE
160 71 Trip L3 0 SE
160 74 Fault Forward/Line 0 SE, GI
160 75 Fault Reverse/Busbar 0 SE, GI
160 84 General Start/Pick-up 0 SE, GI
160 85 Breaker Failure 0 SE
160 90 Trip I> 0 SE
160 91 Trip I>> 0 SE
