Siemens 7SR12 Argus User Manual

7SR120 Technical Manual
Chapter 4 - Page 44 of 84 © 2017 Siemens Protection Devices Limited
Address Description Format Mult Description
40056 Vpps FP_32BITS_3DP 1.000000 Vpps Degrees
40058 Vnps FP_32BITS_3DP 1.000000 Vnps Degrees
40060 Frequency FP_32BITS_3DP 1.000000 Frequency Hz
40064 Ia Primary FP_32BITS_3DP 1.000000 Ia A
40066 Ib Primary FP_32BITS_3DP 1.000000 Ib A
40068 Ic Primary FP_32BITS_3DP 1.000000 Ic A
40070 Ia Secondary FP_32BITS_3DP 1.000000 Ia A
40072 Ib Secondary FP_32BITS_3DP 1.000000 Ib A
40074 Ic Secondary FP_32BITS_3DP 1.000000 Ic A
40076 Ia Nominal FP_32BITS_3DP 1.000000 Ia xIn
40078 Ib Nominal FP_32BITS_3DP 1.000000 Ib xIn
40080 Ic Nominal FP_32BITS_3DP 1.000000 Ic xIn
40082 Ia Nominal FP_32BITS_3DP 1.000000 Ia Degrees
40084 Ib Nominal FP_32BITS_3DP 1.000000 Ib Degrees
40086 Ic Nominal FP_32BITS_3DP 1.000000 Ic Degrees
40088 In Primary FP_32BITS_3DP 1.000000 In A
40090 In Secondary FP_32BITS_3DP 1.000000 In A
40092 In Nominal FP_32BITS_3DP 1.000000 In xInom
40094 Ig Primary FP_32BITS_3DP 1.000000 Ig A
40096 Ig Secondary FP_32BITS_3DP 1.000000 Ig A
40098 Ig Nominal FP_32BITS_3DP 1.000000 Ig xInom
40100 Izps Nominal FP_32BITS_3DP 1.000000 Izps xIn
40102 Ipps Nominal FP_32BITS_3DP 1.000000 Ipps xIn
40104 Inps Nominal FP_32BITS_3DP 1.000000 Inps xIn
40106 Izps Nominal FP_32BITS_3DP 1.000000 Izps Degrees
40108 Ipps Nominal FP_32BITS_3DP 1.000000 Ipps Degrees
40110 Inps Nominal FP_32BITS_3DP 1.000000 Inps Degrees
40112 Active Power A FP_32BITS_3DP 0.000001 A Phase W
40114 Active Power B FP_32BITS_3DP 0.000001 B Phase W
40116 Active Power C FP_32BITS_3DP 0.000001 C Phase W
40118 P (3P) FP_32BITS_3DP 0.000001 3 Phase W
40120 Reactive Power A FP_32BITS_3DP 0.000001 Phase A VAr
40122 Reactive Power B FP_32BITS_3DP 0.000001 Phase B VAr
40124 Reactive Power C FP_32BITS_3DP 0.000001 Phase C VAr
40126 Q (3P) FP_32BITS_3DP 0.000001 3 Phase VAr
40128 Apparent Power A FP_32BITS_3DP 0.000001 Phase A VA
40130 Apparent Power B FP_32BITS_3DP 0.000001 Phase B VA
40132 Apparent Power C FP_32BITS_3DP 0.000001 Phase C VA
40134 S (3P) FP_32BITS_3DP 0.000001 3 Phase VA
40136 Power Factor A FP_32BITS_3DP 1.000000 Phase A
40138 Power Factor B FP_32BITS_3DP 1.000000 Phase B
40140 Power Factor C FP_32BITS_3DP 1.000000 Phase C
40142 Power Factor(3P) FP_32BITS_3DP 1.000000 3 Phase
40144 Act Energy Exp UINT32 1.000000 Act Energy Exp
40146 Act Energy Imp UINT32 1.000000 Act Energy Imp
40148 React Energy Exp UINT32 1.000000 React Energy Exp
40150 React Energy Imp UINT32 1.000000 React Energy Imp
40152 Thermal Status Ph A UINT16 1.000000 Thermal Status Ph A %
40153 Thermal Status Ph B UINT16 1.000000 Thermal Status Ph B %
