Siemens 7SR12 Argus User Manual

Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 45 of 84
Address Description Format Mult Description
40154 Thermal Status Ph C UINT16 1.000000 Thermal Status Ph C %
40167 Fault Records UINT16 1.000000 Fault Records
40168 Event Records UINT16 1.000000 Event Records
40169 Waveform Records UINT16 1.000000 Waveform Records
40170 Vab Secondary FP_32BITS_3DP 1.000000 Vab V
40172 Vbc Secondary FP_32BITS_3DP 1.000000 Vbc V
40174 Vca Secondary FP_32BITS_3DP 1.000000 Vca V
40176 Vn Primary FP_32BITS_3DP 1.000000 Vn V
40178 Vn Secondary FP_32BITS_3DP 1.000000 Vn V
40180 Vn Secondary FP_32BITS_3DP 1.000000 Vn Degrees
40193 I Phase A Max FP_32BITS_3DP 1.000000 Ia Max Demand
40195 I Phase B Max FP_32BITS_3DP 1.000000 Ib Max Demand
40197 I Phase C Max FP_32BITS_3DP 1.000000 Ic Max Demand
40199 P 3P Max FP_32BITS_3DP 0.000001 Power Max Demand
40201 Q 3P Max FP_32BITS_3DP 0.000001 VARs Max Demand
40207 Isef Primary FP_32BITS_3DP 1.000000 Isef A
40209 Isef Secondary FP_32BITS_3DP 1.000000 Isef A
40211 Isef Nominal FP_32BITS_3DP 1.000000 Isef xInom
40241 CB Total Trip Count UINT32 1.000000 CB Total Trip Count
40243 CB Delta Trip Count UINT32 1.000000 CB Delta Trip Count
40245 CB Count To AR Block UINT32 1.000000 CB Count to AR Block
40247 CB Frequent Ops Count UINT32 1.000000 CB Frequent Ops Count
40301 Ia Last Trip FP_32BITS_3DP 1.000000 Ia Fault
40303 Ib Last Trip FP_32BITS_3DP 1.000000 Ib Fault
40305 Ic Last Trip FP_32BITS_3DP 1.000000 Ic Fault
40307 Va Last Trip FP_32BITS_3DP 1.000000 Va Fault
40309 Vb Last Trip FP_32BITS_3DP 1.000000 Vb Fault
40311 Vc Last Trip FP_32BITS_3DP 1.000000 Vc Fault
40313 In Last Trip FP_32BITS_3DP 1.000000 In Fault
40315 Ig Last Trip FP_32BITS_3DP 1.000000 Ig Fault
40317 Isef Last Trip FP_32BITS_3DP 1.000000 Isef Fault
40319 V Phase A Max FP_32BITS_3DP 1.000000 Va Max Demand
40321 V Phase B Max FP_32BITS_3DP 1.000000 Vb Max Demand
40323 V Phase C Max FP_32BITS_3DP 1.000000 Vc Max Demand
40341 LED1-n BITSTRING 0.000000 Led 1-16 status
40342 LED1-n BITSTRING 0.000000 Led 17-32 status
40343 INP1-n BITSTRING 0.000000 Input 1-16 status
40344 INP1-n BITSTRING 0.000000 Input 17-32 status
40345 OUT1-n BITSTRING 0.000000 Output 1-16 status
40346 OUT1-n BITSTRING 0.000000 Output 17-32 status
40347 VRT1-n BITSTRING 0.000000 Virtual 1-16 status
40348 VRT1-n BITSTRING 0.000000 Virtual 17-32 status
40349 EQN1-n BITSTRING 0.000000 Equation 1-16 status
40350 EQN1-n BITSTRING 0.000000 Equation 17-32 status
40354 CB Wear A FP_32BITS_3DP 0.000001 CB Wear A
40356 CB Wear B FP_32BITS_3DP 0.000001 CB Wear B
40358 CB Wear C FP_32BITS_3DP 0.000001 CB Wear C
40360 CB Wear A Remaining FP_32BITS_3DP 1.000000 CB Wear A Remaining
