7SR120 Technical Manual
Chapter 4 - Page 60 of 84 © 2017 Siemens Protection Devices Limited
Binary Input Points
Static (Steady-State) Object Number: 1 (Packed Format)
Change Event Object Number: 1 (w/o Time)
Static Variation reported when variation 0 requested: 1 (Binary Input w/o status)
or 2 (Binary Input with status)
Change Event Variation reported when variation 0 requested: 1 (Binary Input Change w/o Time)
or 2 (Binary Input Change with Absolute Time)
or 3 (Binary Input Change with Relative Time)
Point
Index
Description
Default Change Event
Assigned Class
(1, 2, 3 or none)
Default Variation
Static Object 1
Default Variation
Event Object 2
412 Setting G2 selected 0,2 2 2
413 Setting G3 selected 0,2 2 2
414 Setting G4 selected 0,2 2 2
420 79 AR In progress 0,2 2 2
422 HotLine Working 0,2 2 2
425 Inst Protection Out 0,2 2 2
427 CB 1 0,2 2 2
501 Virtual Input 1 0,2 2 2
502 Virtual Input 2 0,2 2 2
503 Virtual Input 3 0,2 2 2
504 Virtual Input 4 0,2 2 2
505 Virtual Input 5 0,2 2 2
506 Virtual Input 6 0,2 2 2
507 Virtual Input 7 0,2 2 2
508 Virtual Input 8 0,2 2 2
601 LED 1 0,2 2 2
602 LED 2 0,2 2 2
603 LED 3 0,2 2 2
604 LED 4 0,2 2 2
605 LED 5 0,2 2 2
606 LED 6 0,2 2 2
607 LED 7 0,2 2 2
608 LED 8 0,2 2 2
609 LED 9 0,2 2 2
701 LED PU 1 0,2 2 2
702 LED PU 2 0,2 2 2
703 LED PU 3 0,2 2 2
704 LED PU 4 0,2 2 2
705 LED PU 5 0,2 2 2
706 LED PU 6 0,2 2 2
707 LED PU 7 0,2 2 2
708 LED PU 8 0,2 2 2
709 LED PU 9 0,2 2 2
801 Binary Output 1 0,2 2 2
802 Binary Output 2 0,2 2 2
803 Binary Output 3 0,2 2 2
804 Binary Output 4 0,2 2 2
805 Binary Output 5 0,2 2 2
806 Binary Output 6 0,2 2 2
807 Binary Output 7 0,2 2 2
808 Binary Output 8 0,2 2 2
871 Cold Start 0,2 2 2
