Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 61 of 84
Binary Input Points
Static (Steady-State) Object Number: 1 (Packed Format)
Change Event Object Number: 1 (w/o Time)
Static Variation reported when variation 0 requested: 1 (Binary Input w/o status)
or 2 (Binary Input with status)
Change Event Variation reported when variation 0 requested: 1 (Binary Input Change w/o Time)
or 2 (Binary Input Change with Absolute Time)
or 3 (Binary Input Change with Relative Time)
Point
Index
Description
Default Change Event
Assigned Class
(1, 2, 3 or none)
Default Variation
Static Object 1
Default Variation
Event Object 2
872 Warm Start 0,2 2 2
873 Re-Start 0,2 2 2
874 Power On 0,2 2 2
875 Expected Restart 0,2 2 2
876 Unexpected Restart 0,2 2 2
877 Reset Start Count 0,2 2 2
890 CB 1 Opened 0,2 2 2
891 CB 1 Closed 0,2 2 2
900 User SP Command 1 0,2 2 2
901 User SP Command 2 0,2 2 2
902 User SP Command 3 0,2 2 2
903 User SP Command 4 0,2 2 2
904 User SP Command 5 0,2 2 2
905 User SP Command 6 0,2 2 2
906 User SP Command 7 0,2 2 2
907 User SP Command 8 0,2 2 2
1063 CB DBI 0,2 2 2
1064 CB Travelling 0,2 2 2
1065 Close CB Failed 0,2 2 2
1066 Open CB Failed 0,2 2 2
1067 Start Count Alarm 0,2 2 2
1068 50AFD PhA 0,2 2 2
1069 50AFD PhB 0,2 2 2
1070 50AFD PhC 0,2 2 2
1071 50AFD 0,2 2 2
1072 AFD Zone 1 Flash 0,2 2 2
1073 AFD Zone 1 0,2 2 2
1074 AFD Zone 2 Flash 0,2 2 2
1075 AFD Zone 2 0,2 2 2
1076 AFD Zone 3 Flash 0,2 2 2
1077 AFD Zone 3 0,2 2 2
1078 AFD Zone 4 Flash 0,2 2 2
1079 AFD Zone 4 0,2 2 2
1080 AFD Zone 5 Flash 0,2 2 2
1081 AFD Zone 5 0,2 2 2
1082 AFD Zone 6 Flash 0,2 2 2
1083 AFD Zone 6 0,2 2 2
5.3.2 Double Bit Input Points
