Siemens Cerberus CS1140 User Manual

B3Q4.. / 560 Control terminal AlgoPilot
170
Building Technologies 001260_k_en_--.doc
Fire Safety & Security Products 02.2005
42.2 Application
z Remote location for the AlgoPilot:
– either with own local power supply, or 24 V supplied from the control unit
z Option ’9 V battery’:
– Allows fault indication upon total failure of power supply (mains + battery) see
page 172
z EPROM+/RAM set
– According to system size (table of quantities) choose the corresponding
EPROM+RAM set
– Processing capacity see document ’Planning’ (1076 EP5, 008725 EP7F-Z1)
EPROM set RAM set
for
Control
terminal
’CT’
Parallel
control
terminal ’CA’
Control terminal
and main CPU
combined ’CI’
Notes
for application
’CT’ and ’CI’
for application
’CA’
Notes
CTQ00xxx CAR00xxx 2x 512Kx8Bit international
Z3S080
(2x 256Kx8Bit)
1 Set
B3Q4..
CIQ00xxx 2x 1024Kx8Bit international 1 Set
CTQT1xxx CAQT1xxx CIQT1xxx 1 Set
CIWT1xxx
2x 1024Kx8Bit China simplified
2 Sets
CTQTExxx CAQTExxx CIQTExxx 1 Set
CIWTExxx
2x 1024Kx8Bit China traditional
2 Sets
CTQTLxxx CAQTLxxx CIQTLxxx 1 Set
CIWTLxxx
2x 1024Kx8Bit Korea standard
2 Sets
CTQT5xxx CAQT5xxx CIQT5xxx 1 Set
B3Q560
CIWT5xxx
2x 1024Kx8Bit Thailand
Z3S070
(2x 512Kx8Bit)
2 Sets
Recommended EPROMs: 27C040, 27C4001 (512Kx8Bit, 100 ns, DIP32) and
27C801 (1024Kx8Bit, 100 ns, DIP32)
42.3 Key data
B3Q4.. B3Q560
Operating voltage 18...45 VDC 18...45 VDC
Quiescent current (illumination of the LCD inactive) 100 mA (24 V) 75 mA (24 V)
Maximum current (LCD backlight active + lamp test) 400 mA (24 V) 260 mA (24 V)
42.4 Functions
Interfaces
– C-Bus –> Plug-in terminals ’K5’
– I-Bus –> Connector ’ST1’
– 2 x RS232 –> Connector ’ST2’
– Parallel indicator panel B3R051, Mimic Display board /K3R071/072 –> Connec-
tor ’ST4’
– Emergency operation circuit –> Plug-in terminals ’K6’
Control inputs
– external key switch (see Operation enabled)
– monitoring of autonomous power supply
– monitoring of Plexiglas door (open / closed)
Operation enabled
– this is normally done via password at the keyboard
– an integrated key switch, (photoelectric) is available as an option which can also
be used to lock the Plexiglas door (if used).
– operation can also be enabled by an external key switch
