Siemens SIMATIC PCS7 Function Manual

Diagnostics for ... Area MS Ba‐
sic
MS Standard SIMATIC
PDM MS
● CPU
● CP
● SIMATIC PCS 7 BOX
● Interface module (IM) of the ET 200
families
(ET 200M, ET 200S, ET 200SP,
ET 200iSP,
ET 200pro)
● Link modules
(DP/PA-Link, Y-Link, FF Link,
Compact FF Link)
AS/system X -
● Interface module (IM) of the ET 200
families
● Input and output modules of the ET 200
families
● Failsafe modules
● Link modules
● PROFIBUS devices
● PROFINET devices
● Field devices (HART, PROFIBUS PA, ...)
● Non-transparent couplers with
diagnostics capability
● Diagnostic repeaters
Field devices - X -
● EDD objects can be detected by SIMATIC
PDM
● Field devices (HART, PROFIBUS PA, ...)
● Interface modules (IM) of the ET 200
families
● Input and output modules of the ET 200
families
● Link modules
● Non-transparent couplers with
diagnostics capability
● Station objects (gateways)
Field devices - X
● User objects for which a diagnostics can
be generated by an application
User objects - X -
Using the Maintenance Station
3.2 Components with diagnostics capability
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 17
