Batch control
Batch control is a BATCH flexible application which sits on top of the OS
system (WinCC).
The following tasks are performed by batch control:
R Batch visualization and operating
R Execution of the batches
The interfaces of batch control with the OS system and with batch data
preparation are described below.
This chapter also deals with the user interface and the philosophy behind
batch control.
This chapter deals with the following topics:
Chapter Topic Page
5.1 Tasks of batch control 5-3
5.2 Starting the program and the user interface 5-4
5.2.1 Batch status list 5-7
5.2.2 Equipment occupancy list 5-10
5.3 Batch visualization and operator actions 5-12
5.3.1 Switching mode 5-16
5.3.2 Execution of the batches 5-18
5.3.3 Equipment allocation procedure 5-22
5.3.4 Online changes 5-23
5.3.5 Exception handling 5-24
5.4 Interfaces of batch control 5-26
5.4.1 Interface with the OS data manager 5-28
5.4.2 Interface with the OS signaling system 5-30
5.4.3 Interface with batch data preparation 5-31
