Programming and Operating Manual (Milling)
260 6FC5398-4DP10-0BA1, 01/2014
G331 Thread interpolation N10 SPOS=... ; Spindle in
position control
N20 G331 Z... K... S... ;
tapping
compensating
chuck e.g. in Z axis; RH or LH
thread is defined via the sign
of the pitch (e.g. K+):
+ : as with M3
- : as with M4
G332 Thread interpolation - retraction G332 Z... K... ;
,
e.g. in Z axis,
; sign of pitch as for
G331
G4 Dwell time 2: Special motions, non-modal G4 F...;separate block, F:
Time in seconds
or
G4 S.... ;separate block, S: in
spindle revolutions
G63 Tapping with compensating chuck G63 Z... F... S... M...
G74 Reference point approach G74 X=0 Y=0 Z=0; separate
block, (machine axis
identifier!)
G75 Fixed point approach G75 X=0 Y=0 Z=0; separate
block, (machine axis
identifier!)
G147 SAR - Approach with a straight line G147 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G148 SAR - Retract with a straight line G148 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G247 SAR - Approach with a quadrant G247 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G248 SAR - Retract with a quadrant G248 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G347 SAR - Approach with a semicircle G347 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G348 SAR - Retract with a semicircle G348 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
TRANS Translation, programmable 3: Write memory, non-modal
TRANS X... Y... Z...; separate
block
ROT Rotation, programmable ROT RPL=... ; rotation in the
current plane G17 to G19,
separate block
SCALE Programmable scaling factor SCALE X... Y... Z... ; scaling
factor in the direction of the
specified axis, separate block
MIRROR Programmable mirroring MIRROR X0; coordinate axis
whose direction is changed,
separate block
ATRANS Additive translation, programming ATRANS X... Y... Z... ;
separate block
AROT Additive programmable rotation AROT RPL=... ; rotation in the
current plane G17 to G19,
separate block
