Siemens SINUMERIK 808D ADVANCED Programming And Operating Manual

Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA1, 01/2014
261
Address
Significance
Value assignments
Information
Programming
ASCALE Additive programmable scaling factor ASCALE X... Y... Z...; scaling
factor in the direction of the
specified axis, separate block
AMIRROR Additive programmable mirroring AMIRROR X0 ; coordinate
axis whose direction is
changed, separate block
G110 Pole specification relative to the last
programmed setpoint position
G110 X... Y... ; Pole
specification, Cartesian, e.g.:
for G17
G110 RP=... AP=... ; Pole
specification, polar, separate
block
G111 Pole specification relative to origin of
current workpiece coordinate system
G111 X... Y... ; Pole
specification, Cartesian, e.g.:
for G17
G111 RP=... AP=... ; Pole
specification, polar, separate
block
G112 Pole specification, relative to the last valid
POLE
G112 X... Y... ; Pole
specification, Cartesian, e.g.:
for G17
G112 RP=... AP=... ; Pole
specification, polar, separate
block
G17 * X/Y plane 6: Plane selection, modally
effective
G17 .... ; Vertical axis on this
plane is tool length
G18 Z/X plane
G19 Y/Z plane Compensation axis
G40 * Tool radius compensation OFF 7: Tool radius compensation,
modally effective
G41 Tool radius compensation left of contour
G42 Tool radius compensation right of contour
G500 * Settable work offset OFF 8: Settable work offset,
modally effective
G54 1. Settable work offset
G55 2. Settable work offset
G56 3. Settable work offset
G57 4. Settable work offset
G58 5. Settable work offset
G59 6. Settable work offset
G53 Non-modal skipping of the settable work
offset
9: Suppression of settable
work offset, non-modal
G153 Non-modal skipping of the settable work
offset including base frame
G60 * Exact stop 10: Approach behavior,
modally effective
G64 Continuous-path mode
G62 Corner deceleration at inside corners when
tool radius offset is active (G41, G42)
Only in conjunction with
continuous-path mode
G62 Z... G1
G9 Non-modal exact stop 11: Exact stop, non-modal
G601 * Exact stop window, fine, with G60, G9 12: Exact stop window,
modally effective
G602 Exact stop window, coarse, with G60, G9
G621 Corner deceleration at all corners Only in conjunction with
continuous-path mode.
G621 AIDS=...
G70 Inch dimension data input 13: Inch/metric dimension
