Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
280 Holmgr. for Σi P.System Data
1
NO
YES
NO Holmgreen-conn. (for fast
sum-i-monit.)
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another
Setting Group
310 Iph-PRIM ref. P.System Data
1
10 .. 50000 A 400 A Primary refer. phase
current for prot.
311 Iph-LPCT PRIM P.System Data
1
1 .. 5000 A 400 A Rated primary phase
current LPCT
312 Ignd-PRIM ref. P.System Data
1
1 .. 50000 A 60 A Primary refer. ground
current for prot.
313 Ignd-LPCT PRIM P.System Data
1
0.01 .. 5000.00 A 2.00 A Rated primary ground
current LPCT
314 Vph-LPCT SEC P.System Data
1
10.0 .. 1000.0 mV 225.0 mV Rated secondary phase
voltage LPCT
315 Vgnd-LPCT SEC P.System Data
1
10.0 .. 1000.0 mV 225.0 mV Rated secondary ground
voltage LPCT
320A Corr.factor IL1 P.System Data
1
0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL1
321A Corr.factor IL2 P.System Data
1
0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL2
322A Corr.factor IL3 P.System Data
1
0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IL3
323A Corr.factor IE P.System Data
1
0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IE
324A Corr.factor IEE P.System Data
1
0.9000 .. 1.1000 1.0000 Correction factor for
magnitude IEE
330 V-LPVT SEC P.System Data
1
3.00 .. 17.00 V 3.25 V rated secondary voltage
LPVT
332A V-LPVT PHA P.System Data
1
-10.00 .. 10.00 ° 0.00 ° phase angle LPVT
401 WAVEFORM-
TRIGGER
Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
402 WAVEFORM DATA Osc. Fault Rec. Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
403 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Wave-
form Capture Record
404 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior
to Trigger
405 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after
Event
406 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary
Input
610 FltDisp.LED/LCD Device, General Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
Functions, Settings, Information
F.2 Settings
476 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
